Lampholder GZ10
货号:
25.828.1000-0
EAN:
-
-
-
-
-
max. ø 1,8 mm
-
GZ10
产品信息 "Lampholder GZ10"
- Wires permanently installed after insertion
- cURus: File E-93328
- cURus: File E-93328
| Ausführung: | Line Voltage Halogen Lampholder GZ10 |
|---|---|
| Connector: | Push-wire contacts for parallel side wiring |
| Halogen lamp high-voltage: | GZ10 |
| Lamp: | for GZ10 |
| Material: | Housing: Ceramic / PPSContacts: CrNi |
| Note warranty conditions: | *Warranty conditions of BJB GmbH & Co. KG as stated as available via the Internet under https://www.bjb.com/en/legal-information/general-terms-and-conditions/ are valid. |
| Packaging quantity: | 500 |
| Producttype: | Line Voltage Halogen Lampholder GZ10 |
| Series: | Line Voltage Halogen Lampholders |
| UL: | yes |
| Weight: | 14 g |
| approbation: | cURus |
| mounting method 1: | Screw mount |
| old article number: | 25.828.1000.00 |
Available CAD Downloads
证书
| 货物编号 | 状态： | 描述： | 文档 |
|---|---|---|---|
| 25.828.1000-0 | cURus_(USA_and_Canada)--703640 | ||
| 25.828.1000-0 | CQC_Genehmigung_liegt_vor_--CQC_approval_at_hand_-3500058 | ||
| 25.828.1000-0 | EAC_Genehmigung_liegt_vor_--EAC_approval_at_hand_-4805042 | ||
| 25.828.1000-0 | ENEC_Zeichen_--ENEC_Approval_-690285 |
-
-
-
-
max. ø 1,8 mm
-
GZ10
